Radiators
Radiators Overview
Tubes and fins assembly is efficiently brazed in electronic oven to guarantee a uniform heat transfer in your radiator. Whether your radiator is for a vehicle, motor pump or a multi-megawatt generator, we can offer you the solution.
Please provide our sales team with the equipment, manufacturer, and model number to select and quote the proper replacement.
GALLERY
CONSTRUCTION OPTIONS
|
Component |
Material |
Type & Dimensions |
|
Tubes |
Copper, Aluminum, Steel, Stainless Steel, Copper- Nickel |
Diameter: 5/16”, 3/8”, ½”, 5/8” Wall Thickness: 0.012”- 0.049” |
|
Fins |
Aluminum, Copper |
Shine Wave, Flat or corrugated. Thickness: 0.006”, 0.008”, 0.010” |
|
Frame |
Galvanized, 304 & 316 Stainless Steel, Aluminum, Copper |
Gauges: 12, 14, 16, 18 |
|
Connections |
Copper, Steel, Red Brass, Stainless Steel |
Sweat, NPT, Grooved, Flanged. From ½” to 4” |
|
Coating |
AA, Heresite, Electro-Fin, Blygold PPG |
|
|
Accessories |
Intermediate drain pan, Drain/Vent Connections, Turbulators |
|
Certification stamps
